L3MA
User Advantages
- Class 300 ANSI flange adaptors: designed for the flange loads according to API standards
- Steel liner: Fully complies with the requirements of the API 676 3rd
- Cast iron idlers: for optimum running properties under critical conditions
- Single mechanical seal subjected only to suction pressure, API 682 cartridge seal optional
- No special internal coatings required
- Axial inlet for ease of piping
- Single bearing
- Hydro-dynamically balanced rotors → no thrust bearing required
- Quiet operation → No pulsation
General Use
The new L3MA pump is an API 676 compliant triple screw pump. Due to the use of a new spindle material it is possible to have the spindles run directly in a steel casing.
Attachments:
